Solenoid
                                                                                                   Solenoids                                                                                                                    Solenoids

       CHARACTERISTICS                                                                  DC         AC                              Solenoid SIN60V
       Static pressure tightness   350 bar (seal diameter of valve    Totale stroke  (mm)   5,5    5,5                             to VDE 0580
                            max. 25 mm)                     Working stroke       (mm)   2,5        2,5                             Plug plate to ISO 4400 / DIN 43650
                            With seal diameter of valve = 26 mm:  Nominal power       (W)   30
                            Static pressure tightness = 315 bar                (VA)                35                              Protection class IP65
       Coil winding insulation class  H                     Armature weight    (kg)     0,044      0,044
       Connection / Power supply   Over device plug connection to    Solenoid weight       (kg)   0,76  0,76
                            ISO 4400 / DIN 43650, (2P+E),    Voltage range       (VDC)   10-250
                            other connections on request                       (VAC)               40-250*
       Protection class to EN 60 529  IP65                                                                                         DESCRIPTION                        fuNCTION                           APPLICATION
       Relative duty factor   100 %                                                                                                The SIN60V is a switching solenoid. Its design   When the solenoid is energised with the speci-  Essential for hydraulic directional and poppet
       Reference temperature   50 °C                        ∗   For AC voltages below 40 VAC DC solenoids plus rectifier plugs     corresponds to VDE standard 0580. The steel   fied nominal voltage, the armature moves from   valves. Because of the risk of overheating, the
       Seal                 Viton, other on request              are available.                                                    housing is zinc coated as a standard. Static   the starting position of its stroke (s = 8,5 mm) to   solenoid must never be used separately. The
                                                              21 VDC  to  24 VAC
       Fluid                Mineral oil, other fluid on request                                                                    pressure tightness is 160 bars. All o-rings are   the end position (s = 0 mm). The switching time   lenght of the fixing screws depends on the base
       Switching cycles     15 000/h                           32 VDC  to  36 VAC                                                  Viton. The  solenoids  are  fixed  to  the  valve   is essentially dependent on the application.   material of the body. An o-ring is used for the
       Mounting screws      4 x M5 (Quality 8.8)                                                                                   with four screws. Depending on the intended   The power-stroke characteristics are designed   valve seal. Information on screws and o-rings
       Housing              Zinc coated steel housing, other                    12VDC   24VDC   115VAC  230VAC                     use, the solenoid can be supplied with a plug   to suit the requirements of hydraulic valves.   will be found in the data sheets relating to the
                            surface treatments on request.  Nominal resistance (Ω)   5   21,8   445   1'400                        screw, or with integrated manual override. The   AC  versions  include  an  electronic  rectifier   valves concerned. Before changing the plug
                                                            Number of windings (-)   770   1’560   7’000   13’000                  connector plate corresponds to ISO 4400 and   integrated into the connector plate. In this way   screw or the screw with integrated manual
                                                                                                                                                                                                         override, care must be taken to ensure that the
                                                                                                                                   DIN 43650.
                                                                                                                                                                      maximum perfor-mance is assured.
                                                            Inductivity (mH)    19     82                                                                                                                solenoid is not under pressure. Risk of injury!
                                                                                                                                                                                                         The maximum operating pressure is determin-
                                                                                                                                                                                                         ded by the valve actually used.
                                                                                                                                                                      TyPE CODE
                                                                                                                                                                                                                 SI  N  60  V  -   -   #
                                                                                                                                                                      Solenoid
       PERfORMANCE                                          ACCESSOIRES                                                                                               Industrial execution
       F = f (s)   Force-stroke characteristics                                                                                                                       Normal
                                                            Plug HB0                         ∗ Article No. 239.2033
          F [N]                                             Plug with integrated manual override HB6   ∗ Article No. 253.8001                                         Square 60 mm housing
        160  K0062                                                                         ∗ acc. data sheet 1.1-300                                                  Solenoid completly potted
                                                                                                                                                                      Nominal voltage U         12 VDC     G12
                                                                                                                                                                                   N
        140                                                 Special manual override         see data sheet 1.1-310                                                                              24 VDC     G24
                                                                                                                                                                                                115 VAC    R115  ∗
                                                            Plug grey                         Article No. 219.2001                                                                              230 VAC    R230  ∗
        120                                                 Plug black                        Article No. 219.2002                                                    AC= 50 to 60 Hz
                                                                                                                                                                      ∗ Rectifier integrated in the plug
                                                            Rectifier plug grey               Article No. 219.2105
        100                                                                                                                                                           Other nominal voltages and nominal power on request
                                                            Rectifier plug black              Article No. 219.2106
         80                                                                                                                                                           with mounted screw plug (data sheet 1.1-300)   HB0
                                                                                                                                                                      with mounted manual override (data sheet 1.1-300)   HB8,5
                                                                                                                                                                      with mounted special manual override (data sheet 1.1-310)   H...
         60
                               1                                                                                                                                      Design-Index (Subject to change)

         40
                         2                                                                                                         DIMENSIONS
         20                                                                                                                                                                                                              9,2


          0
           0    1     2    3    4    5    s [mm]
                                                                                                                                        8 x0,75

                                                                                                                                        M                               4,9     99
                                                                                                                                     20                                    32  70,5                                                   7  14
                                                                                                                                                                                                            6,5
       1: U = 100 % U    Reference temperature = 20 °C (30W)
                 N
       2: U = 90 % U    Reference temperature = 50 °C
                N
                     Solenoid in operating temperature (19W)
       The values refer to U  = 24 VDC.                                                                                                        0,3                2,2                           48,08
                      N
       With other nominal voltages deviations can occur.
       For curve 2 the solenoid has been mounted on a body  46 x 64.                                                                                81,5                                         60
                                                                                                                                                     85                                                                       10*
                                                                                                                                    * Solenoid energised (s= 0 mm)
                                                            Technical explanation see data sheet 1.1-400

       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-125E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-145E 1/2
       CH-3714 Frutigen                                                                            Edition 06 20                   CH-3714 Frutigen                                                                             Edition 05 01
