1           2           3          4           5           6           7           8
                                                                                                                                                   MKY45/18x60-.../L..-K9M248
                                                                                                                                                                                                 (2 : 1)               MKY45/18x60-.../L..-K9 Solenoids
                                                                                                                                                                             Ex db IIC T6, T4 Gb
                                                                                                                                                A                                                                                              A
                                                                                                                                   Solenoid coil MKY45/18x60                 Ex tb IIIC T80°C, T130°C Db
                                                                                                                                   For explosion-hazard zones                Ex db I Mb
                                                                                                                                   Protection class IP65/66/67                                  (2 : 1)
                                                                                                                                   Surface AISI 316L                             II 2 G Ex db IIC T6, T4
                                                                                                                                   Optional with integrated amplifier            II 2 D Ex tb IIIC T80°C, T130°C                               B
                                                                                                                                                B
                                                                                                                                   electronics
                                                                                                                                                                                 I M2 Ex db I Mb

                                                                                                                                   DESCRIPTION                        FUNCTION                           APPLICATION
                                                                                                                                   For explosion-hazard zones         In  combination  with  an  armature  tube,  the   The  solenoid  coil  is  suitable  for  use  in  all
                                                                                                                                   Solenoid coil for explosion-hazard zones.  function of a switching solenoid or of a pro-  explosion-hazard zones, open cast and also
                                                                                                                                   The flameproof enclosures prevents an explo- s36  portional  solenoid  results.  Solenoid  coils  in   in mines.  C
                                                                                                                                                C
                                                                                                                                   sion in the interior from getting outside.   AC - construction have an integrated rectifier.  This signifies, that the coils are certified for
                                                                                                                                                                                                                               s8
                                                                                                                                                                                                                              s2.5
                                                                                                                                   The design prevents a surface temperature  s2.5  All  cable  threaded  joints  certified  for  this   applications in zones with explosion-hazard
                                                                                                                                   capable of igniting.               explosion protection class with a protection   gas, steam, vapour, air and dust mixtures of
                                                                                                                                                      M20x1.5
                                                                                                                                   The steel housing is AISI 316L     class of at least IP65 can be used.  the zones 1/21 and 2/22.
                                                                                                                                                                                                                M20x1.5
                                                                                                                                                                                  125
                                                                                                                                   Optional with integrated amplifier electronics.  The  optional  amplifier  electronics  have  an   Valves for explosion-hazard zones are utilised    114
                                                                                                                                                                       42   analogue interface and can be adjusted by   in:      42
                                                                                                                                                D                     means of push-buttons and 7 segment display   – the shipping- and offshore industries
                                                                                                                                                                                                               18.2
                                                                                                                                                   22   18.2          or by means of the parameterisation software   – the oil- and gas industries
                                                                                                                                                                                                             22

                                                                                                                                                                       24                                                        24
                                                                                                                                                                      PASO.                              – the chemical industry

                                                                                                                                                                                                         – wood processing
                                                                                                                                                      2.3                                                       2.3
                                                                                                                                                            62              47                           – grain mills   62            47
                                                                                                                                                                                                         – the mining application
                                                                                                                                   CERTIFICATES E                                                               02 03 04  08.03.2016  MW BEH BEH         Blatt DB 1.1-S183 ergänzt  Gezeichnet  21.08.2014  BEH TK TK
                                                                                                                                                                                                                                     Geprüft
                                                                                                                                                                                                                 05.06.2018
                                                                                                                                                                                                                        DB-Nummer DB 1.1-183S
                                                                                                                                                                                                                                          21.06.2019
                                                                                                                                                                                                                        Aktualisiert
                                                                                                                                                                                                                 20.06.2019
                                                                                                                                                                                                                                     Freigegeben
                                                                                                                                                                                                                                          21.06.2019
                                                                                                                                                                                                                Rev.  Datum  Name Änderungsnr.  Änderungsbeschrieb  Ersetzt durch:  M 1:1  Serie freigegeben Modellreferenz: Doknr. 0236780 / Konfiguration 005
                                                                                                                                                                                                                                            Gewicht
                                                                                                                                                               Surface gas and dust            Mining           Magnetspule komplett  Ersatz für: DB 1.1-183 Rev.01  1.815 kg
                                                                                                                                                                                                                                             Format
                                                                                                                                                                                                                                     Dok.-Nr.
                                                                                                                                                                                                                                         0158631
                                                                                                                                                                                                                MKY45/18x60 K9M248 #4
                                                                                                                                                                                                                                             A2
                                                                                                                                                                                                                        Dokument darf ohne schriftliche Einwilligung weder kopiert,  Art.-Nr.  DB 1.1-183  Revision
                                                                                                                                                                                                                                             04
                                                                                                                                                                                                                        verwertet noch an Dritte weitergegeben werden.
                                                                                                                                    in accordance  Standard    M224       M238  3  Amplifier 4       5                  Zuwiderhandlung ist strafbar und wird gerichtlich verfolgt.  Blatt 2 von 2
                                                                                                                                                                  2
                                                                                                                                                                                                                              C:\00_Wandfluh\Verkauf\Dokumentation\Reg1.1\DB 1.1-183\0158631
                                                                                                                                                      1
                                                                                                                                    with          -25 °C to…  -40 °C to…  -60 °C to…  M248
                                                                                                                                    ATEX / UKEX       x          x         x          x          x
                                                                                                                                    IECEx             x          x         x          x          x
                                                                                                                                    EAC (GOST Ex)     x          x         x          x          x
                                                                                                                                     CCC              x          x         x          x          x
                                                                                                                                   The certificates can be found on www.wandfluh.com / Accompanying Ex-proof / MKY45/18-..-L..
                                                                                                                                   TYPE CODE
                                                                                                                                                                                                 M  K  Y  45  /  18  x  60  -     /     -  K9  -     #
                                                                                                                                   Mobile execution, metal housing
                                                                                                                                   Terminal box without cable
                                                                                                                                   Explosion proof version Ex d
                                                                                                                                   Housing width 45 mm
                                                                                                                                   Internal coil diameter 18 mm
                                                                                                                                   Coil length 60 mm
                                                                                                                                   Nominal voltage U        12 VDC  G 12   115 VAC  R 115
                                                                                                                                                N
                                                                                                                                                            24 VDC  G 24   230 VAC  R 230
                                                                                                                                   Nominal power P    6 W  L 6   9 W  L 9  15 W  L 15  21 W  L 21
                                                                                                                                                N
                                                                                                                                   Surface
                                                                                                                                   Temperature range   -25°C to ...
                                                                                                                                                    -40°C to ...        M224
                                                                                                                                                    -60°C to ...        M238
                                                                                                                                   Function         Amplifier           M248  only G12 or G24 / up to max. L15
                                                                                                                                                                             not for M224 and M238
                                                                                                                                                    Freewheel diode       M256  do not use for proportional functions
                                                                                                                                                    Bipolar protecting diode   M264  only G24
                                                                                                                                                    Power reduction       M272.  only L6
                                                                                                                                   Design-Index (Subject to change)
                                                                                                                                   Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
                                                                                                                                   Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-183SE 1/5
                                                                                                                                   CH-3714 Frutigen                                                                             Edition 22 11
