Solenoid accessory
                                                                                                Solenoid accessory

            Manual Overrides
            with spring reset
            or combined with spring return and detent






            DESCRIPTION                        FUNCTION                           APPLICATION
            The manual overrides are screwed into the   When commissioning a machine or if the po-  Both types of  manual override can be screwed
            solenoid. Two types of overrides are availab-  wer supply fails, the solenoid function can be   into solenoids with an M8 x 0,75 thread. With
            le: one with spring reset and one with spring   replaced by operating the manual override. In   the manual override it is not possible to bleed
            reset plus locking in the switched position. The   the case of the type with lock, the solenoid can   air from valves. Note: Only restricted use for
            housing is made of brass as standard. The pin   also be held in the end position.  poppet valve.
            is made of stainless steel.





            CONTENT                            TYPES

            DIMENSIONS  ........................................... 1           Manual overrides
                                                Solenoid type           Spring reset      Detent
                                                                        Des.    Art. no.   Des.          Art. no.
                                                Square 29-solenoids (NG3)
                                                BSIIIV                  H1      253.9000   H6            253.9502
                                                SIN29V                  H1      253.9000   H22           253.9012
                                                SIS29V                  H1      253.9000   H22           253.9012
                                                PI29V                   H1      253.9000
                                                Square 35-solenoids (NG4)
                                                BEIIV                   H1      253.9000   H22           253.9500
                                                SIN35V                  H1      253.9000   H6   10       253.9502
                                                SIS35V                  H1      253.9000   H6            253.9502
                                                PI35V                   H1      253.9000               Ø 1,5
                                                Square 45-solenoids (NG6)
                                                SIN45V              Ø 18  Ø 13  H1   253.9000   H19      253.9013
                                                SIS45V                  H1      253.9000   H19           253.9013
                                                PI45V                   H1      253.9000
                                                Square 60-solenoids (NG10)                                M8x0,75
                                                SIN60V                  H21     253.9015  27  H20 6 x H  253.9014
                                                SIS60V                  H21     253.9015   H20           253.9014
                                                                                    37
                                                PI60V                   H21     253.9015
            DIMENSIONS
            Type with spring reset                               Type with spring reset plus locking

                                                                                     H
                                           10                                                   10
                                                  Ø 1,5                                              Ø 1,5

              Ø 18  Ø 13                                            Ø 18  Ø 13

                                                     M8x0,75                                            M8x0,75
                                27       6 x H                                       27       6 x
                              37                                                   37




             Type   x       H      Type   x       H              PARTS LIST
                               H                                   Position   Article   Description
             H1     0     max.10   H19    0,3  10  10
             H22    -2      10     H20    4       10
                                                Ø 1,5
             H6     -1      10     H21    4     max.10            10      160.6076   O-ring ID 7,65x1,78
               Ø 18  Ø 13

                                                  M8x0,75
            Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
                                         6 x
                                27
            Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-310E 1/1
            CH-3714 Frutigen    37                                                                       Edition 23 01
