P. 98

H
                                     H

                                                                                                    Solenoid
                                                                                                   Solenoids                                                                                                                    Solenoids

       TYPE LIST / DIMENSIONS / GENERAL SPECIFICATIONS                                                                             Solenoid with pressure compensation                                   M35
                                                                                                                                   (DC voltage only)

 H                 Connector alignment             Electric wiring         Execution:    M222   with screw terminal
 H                                                                         Example:   SIS35V-G24-M222a
          10    H                    H                                     • 2-pole
                                                                           • DC executions available up to 28 VDC
        20                                                                 • Screw terminal plastic                                DiMenSionS
                                                                           • Connector housing plastic, transparent,
                                                                             removable
                                                                           • Printed circuit board protected with protective
                                                                             varnish                                                                           Use only connector plug (model code Z23) with
                                                  1                                                                                                            drilling for pressure compensation.
                                                                                                                                                               (Order separatly from solenoid).
              M222a               M222b                                    Protection class IP40 with plastic hood installed
 H                                                2    green  green
                                                       grün
                                                          grün
 H
                H
                                                  1
              M222c          M209a M222d
                                                  2
                                                       green   rot red
                                                       grün
                                                  -1
              M222e               M222f                                    I  max  = 1,0 A at 130 °C
                                                                           I    = 1,5 A at 120 °C
                                                  +2                        max
                                                       grün green          I  max  = 2,0 A at 110 °C
 H                                                         * Für Proportional-Magnete
                                                           nicht empfohlen
 H
                             M209b                                                                                                 Dimensions see standard solenoid
        M209a





                                                                                                                                   SpeCifiCationS                                       appliCation
                                                                                                                                   See standard solenoid                                For subsea applications where solenoid is placed in oil filled box and
 H     PARTS LIST                                                                                                                                                                       separated from sea water.


        M209b
        Position   Article   Description
        10      219.2802   Mating connector (M209 and M222)
        20      088.1116   Plastic hood (only M222)                                                                                orDering exeMple SolenoiDS                                            orDering exeMple valve

                                                                                                                                                                         SI  S  45  -   -  M35  -  HB0  #
                                                                                                                                   Solenoid-                                                             WDSFA06 - ACB - G24 - M35
                                                                                                                                   Industry version
                                                                                                                                   Super
            OPERATION SAFETY                                               NOTE!                                                   Square 45 mm housing
            Caution: To avoid overheating, the solenoid may only be energised in com-  For  additional  specifications  and  performance   Nominal voltage U    12 VDC   G12
            bination with a valve.                                         data refer to the corresponding data sheet of the                    N         24 VDC   G24
                                                                           standard solenoid.
                                                                                                                                   Other nominal voltages and nominal performances on request
                                                                           Technical explanation see data sheet 1.1-400            Code for pressure compensation
                                                                                                                                   with mounted plug (data sheet 1.1-300)
                                                                                                                                   Design-Index (Subject to change)






                                                                                                                                   Technical explanation see data sheet 1.1-400

       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-201E 4/4              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-240E 1/1
       CH-3714 Frutigen                                                                            Edition 18 34                   CH-3714 Frutigen                                                                             Edition 03 19
