Solenoid operated spool valve
                                                                                Solenoid operated spool valve                                                                                                Solenoid operated spool valve


       TYPE CODE                                                                                                                   PERFORMANCE SPECIFICATIONS
                                                                                                                                                    2
                                                                WD  Z  F  A04  -     -     -     /     /     -     #               Oil viscosity u = 30 mm /s
       Spool valve direct operated                                                                                                  p = f (Q)  Performance limits 100 Ω                  p = f (Q)  Performance limits 152 Ω
       Explosion proof execution Ex ia                                                                                                 p [bar]                AB_/ACB   ADB  AB3            p [bar]                  AB_ / ACB    AB3
                                                                                                                                      350  K1181                                          350  K4208                   ADB
       Flange construction                                                                                                            300                                                 300
                                                                                                                                      250                                                 250
       Mounting interface according to Wandfluh standard, NG4-Mini                                                                    200                                                 200
                                                                                                                                      150                                                 150
       Designation of symbols acc. to table                                                                                           100                                                 100
                                                                                                                                      50                                                   50
       Spool specification    Standard                                                                                                 0                                                    0
                              Low Leakage   x                                                                                           0      4      8      12     16     20  Q [l/min]     0      4      8     12     16     20  Q [l/min]

       Coil resistance        100 Ω     100
                              152 Ω     152
                                                                                                                                    Δp = f (Q)  Pressure drop volume flow characteristic  Q  = f (p)  Leakage volume flow characteristic
                                                                                                                                                                                          L
       Equipment group        I (Mining)   Z319   only in combination with coil resistance 100 Ω                                                                                                   P → T
                              II (Surface)   T6
                                                                                                                                       p [bar]                                             Q [cm /min]   Standard
                                                                                                                                                                                                3
       Connection execution              D                                                                                            50  K1182                                           80  K1183
                                         K                                                                                            40
                                                                                                                                                                                          60
       Sealing material       NBR                                                                                                     30
                              FKM (Viton)   D1                                                                                        20                                                  40
                                                                                                                                      10                                                  20
       Design index (subject to change)
       1.3-28                                                                                                                          0                                                   0
                                                                                                                                        0      4      8     12     16     20  Q [l/min]     0    50  100  150  200  250  300  350  p [bar]
       GENERAL SPECIFICATIONS                              ELECTRICAL SPECIFICATIONS

                                                                                                                                                                                                3
       Designation        4/2-, 4/3-spool valve             Protection class   IP65                                                                                                        Q [cm /min]   Low leakage
       Construction       Direct operated                   Relative duty factor  Continuous operation                             Attention!  If, because of the given operating conditions, during the   80
                                                                                                                                            switching process volume flows occur which exceed
       Mounting           Flange construction               Switching frequency  1'800 / h                                                  the power limit of the valve, these have to be limited by   60
       Nominal size       NG4-Mini according to Wandfluh    Service life time  10  (number of switching cycles,                             a throttle or an orifice in connection P.     40
                                                                                7
                          standard                                             theoretically)                                               In case of a continuous flow through, the throttle or
       Actuation          Ex-protection switching solenoid  Voltage tolerance  ± 10 % with regard to nominal voltage                        orifice, depending on the system behaviour, an   20
                                                                                                                                            additional heating-up of the valve is possible. This has
       Ambient temperature  -25…+45 °C (operation as T6)    Limiting current at  I  = 90 mA (100 Ω execuiton)                                                                              0
                                                                               min                                                          to be appropriately taken into account by the user.                                  p [bar]
                          -25…+60 °C (operation as T1…T5)   50 °C              I  = 64 mA (152 Ω execuiton)                                                                                 0    50  100  150  200  250  300  350
                                                                               min
       Weight             2,45 kg (1 solenoid)              Temperature class  T1…T6
                          4,65 kg (2 solenoids)             Coil resistance    100 Ω, 152 Ω
       MTTFd              150 years                         Minimum power      P  = 0,81 W (100 Ω execution)                       ACCESSORIES                                          MANUAL OVERRIDE
                                                                                min
                                                            consumption        P  = 0,62 W (152 Ω execution)                                                                            HB4,5 as standard
                                                                                min                                                 Fixing screws                Data sheet 1.0-60
       HYDRAULIC SPECIFICATIONS                            Note!    Other electrical specifications, recommended power              Threaded subplates           Data sheet 2.9-05
                                                                    supply and safety-related limits see data sheet 1.1-185
       Working pressure   p  = 350 bar                                                                                              Multi-station subplates      Data sheet 2.9-45
                           max
       Tank pressure      p    = 200 bar                                                                                            Horizontal mounting blocks   Data sheet 2.9-85
                           T max
       Maximum volume flow  Q  = 20 l/min, see characteristics                                                                      Technical explanations       Data sheet 1.0-100     SEALING MATERIAL
                           max
       Leakage oil        See characteristics                                                                                       Filtration                   Data sheet 1.0-50      NBR or FKM (Viton) as standard, choice in the type code
       Fluid              Mineral oil, other fluid on request                                                                       Relative duty factor         Data sheet 1.1-430
       Viscosity range    12 mm /s…320 mm /s
                                        2
                               2
       Temperature range   -25…+45 °C (operation as T6, NBR)
       fluid              -20…+45 °C (operation as T6, FKM)                                                                        STANDARDS                                            SURFACE TREATMENT
                          -25…+60 °C (operation as T1…T5, NBR)                                                                      Explosion protection  Directive 2014 / 34 / EU (ATEX)  ◆  The valve body is painted with a two component paint
                          -20…+60 °C (operation as T1…T5, FKM)                                                                                                                           ◆  The armature tube, the slip-on coil and the plug screw are
       Contamination      Class 20 / 18 / 14                                                                                        Mounting interface  Wandfluh standard                 zinc-nickel coated
       efficiency                                                                                                                   Protection class   EN 60 529
       Filtration         Required filtration grade ß 10…16 ≥ 75,                                                                   Contamination      ISO 4406
                          see data sheet 1.0-50                                                                                     efficiency
