Solenoids                                                                                                                    Solenoids
                                                                                                    Solenoid

       SPECIFICATIONS                                                                                                              Solenoid coil W.E64/31 x 72
       Insulation material class    H                                                                                              in accordance with DIN VDE 0580
       of the excitation winding
       Protection class acc. to                                                                                                    Protection class IP 65 / 67 / 69K
       EN 60 529           IP65/67, with corresponding cable gland
                           and correct installation
       Relative duty factor   100 % DF
       Admissible ambient temp.  T1…T6: -20…+45 °C
                           T1…T5: -20…+60 °C
       Housing             Steel housing, zinc-nickel                                                                              DEScrIPtIoN                        fuNctIoN                           APPlIcAtIoN
       Relative humidity   max. 95 % (non-condensing)                                                                              The slip-on solenoid coil W.E64/31x72 is   With the combination of an armature tube the   The solenoid coils are mainly utilised in hy-
       Connection / power supply  MKZ45: Standard                                                                                  available in three different connection versions   function of a switching solenoid or of a propor-  draulic applications.
                           • Cable entry for cable ∅ 6…12 mm                                                                       (see type code). The design corresponds to the   tional solenoid results. The solenoid coils are
                           • + external protective terminal                                                                        DIN VDE standard 0580. The housing is made   available with the standard nominal voltages
       Only available      MDZ45: DIN connector in accordance with                                                                 of steel (zinc- / nickel-coated), the connector   12 VDC and 24 VDC.
       for device group II   ISO 4400/DIN 43650                                                                                    socket is made of plastic material.
                           • + external protective terminal
       Technical safety    Equipment group   I   II
       limit values
                           U i         30 V    30 V
                           I  i        3,25 A  0,8 A                                                                               tYPE coDE
                           P i          7 W   3 W                                                                                                                                                              W    E64 / 31  x  72  -   #
                           L i         0mH  0mH                                                                                    Metal housing, round
                           C            0nF   0nF
                            i                                                                                                      Connection execution
                           The inductance and capacitance of                                                                       Connector socket EN 175301-803 / ISO 4400    D
                                                                                                                                   Connector socket AMP Junior-Timer
                                                                                                                                                                               J
                           the solenoid coils are made ineffective.
                                                                                                                                   Connector Deutsch DT04-2P                   G
                                                                                                                                   Coil execution
       RECOMMENDED ELECTRIC POWER SUPPLY
                                                                                                                                   Internal coil diameter 31 mm
        Electric power supply                                    Solenoid
                                                                                                                                   Coil length 72 mm
        Type             Manufacturer  Number   I max   Equipment  Required coil
                                      of outputs        group    resistance                                                        Nominal voltage U N                        12 VDC    G12
        BXNE3412         Georgin         1       95mA      II         100Ω                                                                                                    24 VDC    G24
        BXNE3422         Georgin         2       95mA      II         100Ω                                                         Design-Index (Subject to change)
        KFD2-SLD-Ex1.13100 Pepperl+Fuchs  2     105mA      II      100Ω (152Ω)
        BXNE3712         Georgin         1      125mA      II         100Ω
        BXNE3722         Georgin         2      125mA      II         100Ω
        LB6115/FB6215***  Pepperl+Fuchs  4       80mA      II         152Ω                                                         SPEcIfIcAtIoNS
        9143/10-156-160-10S  Stahl       1      140mA      II         100Ω                                                         Coil winding
                                                                                                                                   insulation class   H (180 °C)
       Further characteristic values refer to data sheet of the power supply manufacturer                                          Relative duty factor   100 % DF / ED
       *** Maximum line resistance 3Ω (corresponds to 80m line length in case of a 1mm cross section).                                                combined with armature tube and valve
                                                                 2
                                                                                                                                   Ambient temperature   -20...+70 °C
                                                                                                                                   Corrosion protection   Salt spray test according to
       SAFE OPERATION                                       ACCESSORIES                                                                               EN ISO 9227:≥ 480 h
       Intrinsically valves must only driven by a suitable electric power supply   –  The operating instructions incl. the EC declaration of conformity for
       (see operating instructions). The selection of the power supply and   solenoid coils of the type M.Z45-... and I.Z45-... is supplied in Ger-
       wiring work must be executed by trained specialists.  man, English and French language and provided for downloading
                                                             under www.wandfluh.com.                                                                            12 VDc    24 VDc
                                                                                                                                   Nominal power (20° C)   (W)   39       38
                                                            –  Type test certifications                                            (Switching function)
                                                              (download under www.wandfluh.com)                                    Limiting current (50° C)   (A)   2,225    1,105
                                                                                                                                   (Proportional function)
                                                            –  Declaration of conformity                                           Limiting power (50° C)   (W)   27,1     26,5
                                                              (download under www.wandfluh.com)                                    (Proportional function)      3,7       15,2
                                                                                                                                   Nominal resistance (20° C) (Ω)
                                                            –  Recognition of production quality assurance                         Weight of solenoid coil   (kg)   1,0      1,0

                                                            - SEV 16 ATEX 4130
                                                              CH/SEV/QAR16.0001
                                                              (Download unter www.wandfluh.com)                                                                                         SAfE oPErAtIoN
                                                                                                                                                                                        caution: Because of the danger of over-heating the solenoid coil must
                                                                                                                                                                                        only be commissioned together with an armature tube as well as with
                                                                                                                                                                                        a valve.



       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-185E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-190E 1/2
       CH-3714 Frutigen                                                                            Edition 22 11                   CH-3714 Frutigen                                                                             Edition 15 08
