Solenoids                                                                                                                    Solenoids
                                                                                                    Solenoid
                       ↓ Valve side
               72                                           Execution: W  D  E64/31 x 72                                           Solenoid coil M..60/31 x 72
               Ø 31                                         • 3-poles 2 P+E                                                        according to VDE 0580
                                                            • Protection class IP 65
                                                            • With corresponding mating connector                                  Protection class IP65 / IP67
                                                            • (not included in delivery)
               72      72                                   • and professional assembly.
               Ø 31
               72
               Ø 64
               Ø 31                                                                                                                DESCRIPTION                                           FUNCTION
                       72
               72                                                                                                                  The slip-on solenoid coil M..60/31 x 72 is available with different types   In combination with the corresponding armature tube the function of an
                                                                                                                                   of electric connections. The AC voltage type incorporates a rectifier.   on-off solenoid or proportional solenoid will be obtained.
                                                                                                                                   The available AC voltages are listed in the type code section. The
               Ø 64    72                                                                                                          construction corresponds to standard VDE 0580. The steel housing is
                                                                                                                                   zinc-/nickel-coated as standard.
                      ↓ Valve side
               72      72
               Ø 64                                         Execution: W  J  E64/31 x 72
                                                            • 2-poles 2P
               72                                           • only for U  ≤ 75 VDC                                                 TYPE CODE
                                                                    N
                                                            • Protection class IP 66
                       72                                   • With corresponding mating connector                                                                                                          M      60 / 31 x 72 -   -   #
              82,9
                                                            • (not included in delivery)                                           Metal housing square
                                                            • and professional assembly.                                           Connection execution
                       72                                                                                                          Connector socket EN175301-803 / ISO 4400  D    Flying leads execution   L  (only DC)
                                                                                                                                   Connector socket AMP Junior-Timer   J  (only DC)  Cable execution   K
              82,9     72                                                                                                          Connector Deutsch DT04-2P       G  (only DC)  Bayonet connector VG 95234  B
                                                                                                                                                                            Screw clamp           X  (only DC)
                      ↓ Valve side                                                                                                 Coil execution   Standard       S        Proportional          A
              82,9                                          Execution: W  G  E64/31 x 72                                           Coil size
                                                            • 2-poles 2P
                       72                                   • only for U  ≤ 75 VDC                                                 Internal coil diameter 31 mm
                                                                    N
                                                            • Protection class IP 67 and 69 K                                      Coil length 72 mm
                                                            • With corresponding mating connector
                       72                                   • (not included in delivery)                                           Voltage          Direct current   G      Alternating current   R
                                                            • and professional assembly.                                           Nominal voltage   12 VDC       12        115 VAC               115
                                                                                                                                                    24 VDC        24        230 VAC               230
                                                                                                                                   Standard
                                                                                                                                   Special cable execution                  M28
                                                                                                                                   With pressure compensation               M35  (only DC)
                                                                                                                                   Special screw clamp                      M209  (only DC)
                                                                                                                                   Screw clamp and electric wiring          M222  (only DC)
                                                                                                                                   Design-Index (Subject to change)


                                                                                                                                   SPECIFICATIONS
                                                            Technical explanation see data sheet 1.1-400 and 1.1-410               Coil winding        min. H (180 °C)                                        12 VDC  24 VDC  115 VAC  230 VAC
                                                                                                                                   insulation class                                     Nominal power    (W)   37,4   37,4    34,1   37,1
                                                                                                                                   Relative duty factor    depending on the connector version    (Switching function)
                                                                                                                                                       IP65 or IP67 according to EN 60 529    Limiting power   (W)   27,5   27,5   –   –
                                                                                                                                                       (if correctly mounted)           (Proportional function)
                                                                                                                                   Relative duty factor   100 % ED / 5 min              Limiting current (50 °C) (A)   2,29   1,14   –   –
                                                                                                                                                       when mounted on armature tube and valve  (Proportional function)  (Ω)   3,9   15,4   309   1146
                                                                                                                                                                                        Nominal resistance
                                                                                                                                   Ambient temperature   See temperature curve on page 4  Number of windings   (–)   725   1 451   6463   12'438
                                                                                                                                   Nominal voltage range   10 – 250 VDC                 Weight of solenoid coil (kg)   1,30   1,30   1,30   1,30
                                                                                                                                                       50 – 250 VAC
                                                                                                                                   Corrosion protection   Salt spray test in accordance with
                                                                                                                                                       EN ISO 9227 > = 1000 hours


                                                                                                                                   SAFE OPERATION                                             NOTE!
                                                                                                                                                                                              The  effective  heat  emissions  depends  on  the  installation
                                                                                                                                         Caution: To avoid overheating the coil may only be energised   conditions (heat emission surface, air circulation, etc.), these
                                                                                                                                         when mounted on an armature tube and valve.          influence the described area of application.







       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-190E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-193E 1/4
       CH-3714 Frutigen                                                                            Edition 15 08                   CH-3714 Frutigen                                                                             Edition 20 27
