Solenoids                                                                                               Solenoids
                                                                                                          Solenoid
 ↓ Valve side
 72  Execution: W  D  E64/31 x 72  Solenoid coil M..60/31 x 72
 Ø 31  • 3-poles 2 P+E  according to VDE 0580
 • Protection class IP 65
 • With corresponding mating connector   Protection class IP65 / IP67
 • (not included in delivery)
 72  72  • and professional assembly.
 Ø 31
 72
 Ø 64
 Ø 31       DESCRIPTION                                           FUNCTION
 72
 72         The slip-on solenoid coil M..60/31 x 72 is available with different types   In combination with the corresponding armature tube the function of an
            of electric connections. The AC voltage type incorporates a rectifier.   on-off solenoid or proportional solenoid will be obtained.
            The available AC voltages are listed in the type code section. The
 Ø 64  72   construction corresponds to standard VDE 0580. The steel housing is
            zinc-/nickel-coated as standard.
 ↓ Valve side
 72  72
 Ø 64  Execution: W  J  E64/31 x 72
 • 2-poles 2P
 72  • only for U  ≤ 75 VDC  TYPE CODE
 N
 • Protection class IP 66
 72  • With corresponding mating connector                                          M      60 / 31 x 72 -   -   #
 82,9
 • (not included in delivery)   Metal housing square
 • and professional assembly.  Connection execution
 72         Connector socket EN175301-803 / ISO 4400  D    Flying leads execution   L  (only DC)
            Connector socket AMP Junior-Timer   J  (only DC)  Cable execution   K
 82,9  72   Connector Deutsch DT04-2P      G  (only DC)  Bayonet connector VG 95234  B
                                                     Screw clamp           X  (only DC)
 ↓ Valve side  Coil execution   Standard    S        Proportional          A
 82,9  Execution: W  G  E64/31 x 72  Coil size
 • 2-poles 2P
 72  • only for U  ≤ 75 VDC  Internal coil diameter 31 mm
 N
 • Protection class IP 67 and 69 K  Coil length 72 mm
 • With corresponding mating connector
 72  • (not included in delivery)   Voltage   Direct current   G    Alternating current   R
 • and professional assembly.  Nominal voltage   12 VDC   12    115 VAC    115
                             24 VDC        24        230 VAC               230
            Standard
            Special cable execution                  M28
            With pressure compensation               M35  (only DC)
            Special screw clamp                      M209  (only DC)
            Screw clamp and electric wiring          M222  (only DC)
            Design-Index (Subject to change)


            SPECIFICATIONS
 Technical explanation see data sheet 1.1-400 and 1.1-410  Coil winding   min. H (180 °C)  12 VDC  24 VDC  115 VAC  230 VAC
            insulation class                                     Nominal power    (W)   37,4   37,4    34,1   37,1
            Relative duty factor    depending on the connector version    (Switching function)
                                IP65 or IP67 according to EN 60 529    Limiting power   (W)   27,5   27,5   –   –
                                (if correctly mounted)           (Proportional function)
            Relative duty factor   100 % ED / 5 min              Limiting current (50 °C) (A)   2,29   1,14   –   –
                                when mounted on armature tube and valve  (Proportional function)  (Ω)   3,9   15,4   309   1146
                                                                 Nominal resistance
            Ambient temperature   See temperature curve on page 4  Number of windings   (–)   725   1 451   6463   12'438
            Nominal voltage range   10 – 250 VDC                 Weight of solenoid coil (kg)   1,30   1,30   1,30   1,30
                                50 – 250 VAC
            Corrosion protection   Salt spray test in accordance with
                                EN ISO 9227 > = 1000 hours


            SAFE OPERATION                                             NOTE!
                                                                       The  effective  heat  emissions  depends  on  the  installation
                  Caution: To avoid overheating the coil may only be energised   conditions (heat emission surface, air circulation, etc.), these
                  when mounted on an armature tube and valve.          influence the described area of application.







 Wandfluh AG   Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.   Wandfluh AG   Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
 Postfach   Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-190E 2/2   Postfach   Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   1.1-193E 1/4
 CH-3714 Frutigen                   Edition 15 08  CH-3714 Frutigen                                      Edition 20 27
